Omron CP1W-8ER I/O expansion unit 8 x relay outputs 2A

The Omron CP1W-8ER is an I/O expansion unit designed for use with Omron’s CP1 series of programmable logic controllers (PLCs). This specific model provides 8 relay outputs, each capable of switching up to 2A. The CP1W-8ER allows for easy expansion of the I/O capacity of the base PLC unit, providing additional control capabilities.

Key Features:

1. Relay Outputs: The unit features 8 relay outputs, suitable for switching a variety of loads including motors, lights, and other actuators.
2. Compatibility: Designed to be compatible with Omron CP1E, CP1L, and CP1H series PLCs.
3. DIN Rail Mounting: Easy to install on a standard DIN rail, simplifying integration into existing control panels.
4. LED Indicators: Each relay output channel has an associated LED indicator for easy status monitoring.

Specifications:

• Model: CP1W-8ER
• Number of Outputs: 8
• Output Type: Relay
• Output Current: 2A per point (max), with a total current limit of 8A for the unit
• Contact Form: SPST-NO (Single Pole Single Throw – Normally Open)
• Output Voltage: 250VAC / 24VDC
• Isolation: Relay outputs are isolated from the PLC’s internal circuitry
• Power Supply: Draws power from the connected PLC base unit
• Operating Temperature: 0°C to 55°C
• Dimensions: 90 x 86 x 50 mm (H x W x D)

Applications:

• Industrial Automation: Used for controlling various actuators and devices in industrial automation systems.
• Process Control: Suitable for expanding the output capacity of process control systems.
• Building Automation: Can be used in building management systems to control lighting, HVAC, and other subsystems.
